| Description |
HT8 |
4RR80 |
| Number of Rolling Rings |
3 |
4 |
| Max Side Thrust |
150 Kg |
300 Kg |
| Max Pitch |
64mm |
64mm |
| Max Shaft Speed |
300 RPM |
250 RPM |
| Max Linear Speed |
19.8 m/min |
16.5m/min |
| Weight |
32 Kg |
38.7 Kg |
| Drive Torque |
32 Kg Cm |
37 Kg Cm |
| Free Movementlever( FM) |
FM1 |
FM1 |
